B908C-连续旋转扭矩传感器

产品详情

B908C-连续旋转扭矩传感器
B908C-连续旋转扭矩传感器
B908C-连续旋转扭矩传感器
B908C-连续旋转扭矩传感器
B908C-连续旋转扭矩传感器



安装尺寸/Mounting Dimension




特点与用途/Features & Applications

电阻应变为敏感元件和集成电路构成的一体产品;

精度高,性能稳定可靠;

电刷供电,可测量正反两方向扭矩值;

两端均为键连接, 安装使用方便;

最高测量转速4000转/分钟。

Constituted by Strain gauge sensitive components and integrated circuits;

High precision with stable and reliable performance;

This sensor is brush power supply, the output is OK for positive and negative torque signal;

Both ends are keyed;

Maximum speed of torque cannot over 4000 r / min.

 配线图/Wiring Code






参数

Specifications

技术指标/Technique

额定容量

Capacity

0.1,0.2,0.3,0.5, 1,2,3,5Nm

输出灵敏度

Rated output

1.0~1.5mV/V

零点输出

Zero balance

±1% F.S.

非线性

Non-linearity

0.2%F.S.

滞后

Hysteresis

0.2%F.S.

重复性

Repeatability

0.1%F.S.

蠕变(30min

Creep(30min)

0.2%F.S.

温度灵敏度漂移

Temp.effect on output

0.1%F.S./10

零点温度漂移

Temp.effect on zero

0.1%F.S./10

输入电阻

Input impedance

350±10Ω

输出电阻

Output impedance

350±10Ω

绝缘电阻

Insulation

2000MΩ/100VDC

激励电压

Recommended excitation

12V

最大激励电压

Maximum excitation

20V

温度补偿范围

Compensated temp range

-10~60

工作温度范围

Operation temp range

-30~60

安全超载

Safe overload

120%F.S.

极限超载

Ultimate overload

150%F.S.

电缆线尺寸

Cable size

3m

防护等级

IP Class

IP66
